1. Definition:

Deep learning is a type of artificial intelligence derived from machine learning where the machine is able to learn by itself, unlike programming with which it simply executes predetermined rules to the letter.

For this article, we will use the library developed by Google Brain " TensorFlow " (version 2.2.0) with the Keras model (which is now integrated  into  TensorFlow).

This article is not intended to teach you about TensorFlow (you will find many tutorials on this subject, including those from Google ). Instead, we will discover how we can use this library within Dynamo with Python and a very simple example.

 2. The Data Set

For this example, the data set to  train our neural network consists of 2 lists:

• a list of points (where only the X and Y coordinates are retrieved)



• a list of booleans that is associated with the list of points.

            if the value is True → the point of the same index of the point list is in the circle

            if the value is False →  the point  of the same index of the point list  is outside the circle

Finally, we generate a last list which is made up of geometric spheres. It will be used to make predictions. The goal is to predict (from the trained neural network) for each sphere if it is located in the circle.

Note:
Obviously we could determine whether the spheres are in the circle from a simple mathematical operation, but that is not the goal here.

 3. The Code

This article is not about performing a model, but about exploring the capabilities of TensorFlow in Dynamo

In the example below, we create a neural network with Keras (which makes operations much easier) that has the following characteristics:

• an input layer consisting of 2 nodes, each node will receive respectively the coordinates and an integer (0 or 1, depending on whether the point is in the circle or not)

• 2 hidden layers composed of 5 nodes

• an output layer with 2 nodes as well

Once the model is created, we train it with the fit() method , and finally we make predictions with predict()

The choice and characteristics of the activation functions, error function and optimizer are not discussed here.

import sys

import clr

import System



clr.AddReference('ProtoGeometry')

from Autodesk.DesignScript.Geometry import *

clr.AddReference('GeometryColor')

from Modifiers import GeometryColor

clr.AddReference('DSCoreNodes')

from DSCore import Color



clr.AddReference('System.Windows.Forms')

import System.Windows.Forms

from System.Windows.Forms import MessageBox, MessageBoxButtons



dirAppLoc = System.Environment.GetFolderPath(System.Environment.SpecialFolder.LocalApplicationData)

sys.path.append(dirAppLoc + r'\python-3.8.3-embed-amd64\Lib\site-packages')

datacsv = dirAppLoc + "\\dataTensorFlow.csv"



# force to reload module

if "tensorflow" in sys.modules:

    del sys.modules["tensorflow"]



import numpy as np

import tensorflow as tf

from tensorflow import keras

from tensorflow.keras import layers

from tensorflow.python.client import device_lib



from io import StringIO



sys.stdout = StringIO()

print("Num GPUs Available: ", len(tf.config.list_physical_devices('GPU')))

print(device_lib.list_local_devices())



LEARNING_RATE = 0.01

EPOCH_COUNT = 2000

max_accuracy = 80

# get X and Y from randoms points

x = np.array([[pt.X, pt.Y] for pt in IN[0]], dtype=np.float32)

# convert bool to integer

y = np.array([int(x) for x in IN[1]], dtype=np.float32)

# get X and Y from Test points for prediction

lstSpheres = IN[2]

testPoints = np.array([[sphere.CenterPoint.X, sphere.CenterPoint.Y] for sphere in lstSpheres], dtype=np.float32)

outGeometry = []



### Different activation ###

# softmax , tanh , relu , sigmoid

#

### Different loss ###

# binary_crossentropy , mean_squared_error , squared_hinge , categorical_crossentropy , sparse_categorical_crossentropy

#

model = keras.Sequential()

model.add(keras.layers.Dense(units=5,  input_shape=x.shape, activation='relu'))

model.add(keras.layers.Dense(units=5, activation='relu'))

model.add(keras.layers.Dense(units=2, activation='sigmoid'))



#optimizer = tf.keras.optimizers.SGD(learning_rate = LEARNING_RATE)

optimizer = tf.keras.optimizers.Adam(learning_rate = LEARNING_RATE)



model.compile(optimizer=optimizer,

              loss='sparse_categorical_crossentropy',

              metrics=['accuracy'])



# train the model

i = 0

final_accuracy = 0

while i < 3 and final_accuracy <= max_accuracy * 0.01:



    model.fit(x, y, epochs=EPOCH_COUNT)

    # get the final accuracy

    final_accuracy = round(model.history.history['accuracy'][-1], 2)

    i += 1



model.summary()

print(f"final_accuracy : {final_accuracy}")

# test Prediction

result1 = model.predict(testPoints)

# color the result

for idx, (sph, (out1, out2)) in enumerate(zip(lstSpheres, result1)):

    factor = 1 if out2 > 0.001 else 0

    print("probability shpere at index {} is inside circle : {}%".format(idx, round((1 - out1) * factor,  2) * 100))

    if out1  < 0.1 and out2 > 0.001:

        geocolor = GeometryColor.ByGeometryColor(sph, Color.ByARGB(255,0,255,0))

        outGeometry.append(geocolor)

    else:

        geocolor = GeometryColor.ByGeometryColor(sph, Color.ByARGB(255,255,0,0))

        outGeometry.append(geocolor)





sys.stdout.seek(0)

readerstdout =  sys.stdout.read()

OUT = readerstdout, result1, outGeometry

NOTE :

• This is a very simple model, in reality it will be necessary to implement:
• A bigger DataSet (more points)
• A validation dataset
• A possibly modified structure of the model with more layers
• An EarlyStopping callback
• The original version of the article and other works of the author can be found here: https://voltadynabim.blogspot.com/2021/07/dynamopython-deep-learning-avec.html

    4. Video Demonstration
